ElecHive 2500 Portable Power Station

Battery

Capacity

2500Wh

Cell Chemistry

NMC(Lithium-Nickel-Manganese Cobalt-Oxide)

Recharging Temperature

32-104°F/ 0-40°C

Operating Temperature

-4-104°F/ -20-40°C

Shelf Life

More than 2 Years (After fully charged)

Life Span

2300 Cycles (80%)

Weight

40lbs/18.3kg

Size

12.9*9.6*11.3 inch/

32.8*24.4 *28.7cm

Storage Temperature & Humidity

-40~140°F/-40 ~60°C, <95%RH

DC Output

12V Anderson Port

10.5~13.4V, 300W/25A Max

24V Anderson Port

19.5~25.2V, 500W/25A Max

12V DC5521 Port

10.5~13.4V, 120W/10A Max

2 x USB-A

5/9/12V, 18W QC3.0

1 x USB-C Bi-direction full PD

5/9/12/15/20V, 100W/5A Max

1 x USB-C

5/9/12V, 18W Max

AC Output

4 x US wall outlet or 3 x Universal wall outlet

110V, 60Hz, 2200W/20A max Continuous, or 230V, 50Hz, 2200W/10A max continuous 4400W Surge Peak

Input / Charge

Normal Charging (Anderson Port)

Solar (Open Circuit Voltage)

240W/10A Max(~11hours to full)

DC Charger 12~30V 240W/10A Max(~11hours to full)

AC Charger 100~240V, 50/60Hz 3.5A(~11hours to full)

Fast Charging (Anderson Port)

Solar (Open Circuit Voltage) 30~75V 1250W/26A Max (~3hours to full)

DC Charger 30~38V 600W/16.7A Max(~5hours to full)

AC Charger 100~130V, 60Hz 6A (US V.)/ 200~240V 50Hz 3.2A(Others V.)(~5hours to full)

DC Charger 42~60V 1250W/26A Max(~2.5hours to full)

AC Charger 100~130V, 60Hz 12A (US V.)/ 200~240V 50Hz 6.5A(Others V.)(~2.5hours to full)

Mode

Auto-sleep switch AC frequency(JP)

ON/OFF (US) 60Hz/50Hz (JP)

Charge/Discharge Percentage

90%/100%
