Baja Designs

Baja Designs LP4 Pro LED Auxiliary Light POD

Baja Designs LP4 Pro LED Auxiliary Light POD

Regular price $424.95
Regular price Sale price $424.95
Sale Sold out
  • The LP4 is the smallest variant in the LP line
  • The LP4 features a total of 8,750 lumens and a 200-degree spread of usable LED light.
  • This light pumps out 7,050 forward-projecting lumens and 1,700 lumens of dedicated peripheral lighting courtesy of our patented Integrated Peripheral Technology (IPT).
  • To keep your light performing at its highest potential, the LP4 integrates our proprietary Direct Ducted Cooling (DDC) technology.




Choose from a variety of patterns to suit your needs:

  • Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 degrees) and spot (8 degrees) optics to provide you with a smooth blend of light for both near-field applications and distance
  • Spot: A longer and narrower 8-degree beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights.


  • Waterproof, Rain Proof, Submersible
  • 5000K Daylight – Less Driver Fatigue, Natural Color


Product Type LP4 Pro LED Light Pod
Description LP4
Beam Pattern Driving/Combo or Spot
Lens Color Amber
Lighting Modes Beam/Day-Time Running Backlighting
Light Quantity 1
Lighting Type Forward Projecting
Lighting Technology LED
Lighting Quantity 4
  6474 / (7.0, 136?) / 395
Brightness (Lumens) 7,050
Wattage (W) 60
Amperage Rating (A) 6.5
Secondary Lighting Type Integrated Peripheral Technology (IPT)
Secondary Lighting Technology LED
Secondary Light Quantity 4 LEDs
Secondary Brightness (Lumens) 1,700
Secondary Wattage (W) 15
Secondary Amperage Rating (A) 1.0
Backlight Wattage (W) 4.83
Backlight Amperage Rating (A) 0.35
Terminal Type Mating Connector
Terminal Connector DT06-4S Deutsch
Average Rated Life (hr.) 49,930
Housing Color Black
Housing Material Hard Anodized Machined Aluminum
Lens Material Hardcoated Polycarbonate
Bezel Material Billet Machined Aluminum
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Wiring Harness Included No
Overvoltage Protection Built-In
Universal or Specific Universal
